Close-up view of the TP0456/CD4614 single-chip calculator circuit used with the TI-60 as Slave processor.
CMOS Technology, 28-pin SPDIP 4-bit Microcontroller, 2,048*9 Bits Instruction ROM, 128*4 Bits Data RAM, 64 Bits Display Register.

Die Photo of the TP0456B/CD4614 courtesy of Sean Riddle.
