Additional Pictures



Close-up view of the TIL370 Four-Digit Clock/Timer LED Display.
Chip-on-Board Technology, 16-pin Package. 4 Digits, Common Cathode, 0.5" Character Height.



Close-up view of the TIL370 Four-Digit Clock/Timer LED Display Reflector Assembly.

Close-up view of the TIL370 Four-Digit Clock/Timer LED Display Printed Circuit Board Assembly.

Close-up view of one character of the TIL370 Four-Digit Clock/Timer LED Display.
Chip-on-Board Technology, 16-pin Package. 4 Digits, Common Cathode, 0.5" Character Height.
