Additional Pictures



The signatures of one transistor each of the 5-channel hybrid module (top, hFE = 160) and 4-channel hybrid module (center, hFE = 260) retrieved
from a Canon LE-85 calculator manufactured in October compared to a 2N3904 General Purpose NPN BJT (bottom, hFE = 180).
